Siglent SDS1302CFL 300MHz 2 Channel
Description
Siglent SDS1302CFL 300MHz 2 Channel
Features and Benefits:
● Memory depth of SDS1000CFL is 24Kpts
● Use Colored TFT LCD, the waveform display is clearer and stable
● Screen saver function: 1 minute to 5 hours
● 2/4 channel-channel bandwidth: 70MHZ-300MHZ
● The real time sampling rate is 2GSa/s
● Trigger Modes: Edge, Pulse, Video, Slope and Alternative trigger modes
● Unique Digital Filter function and Waveform recorder function
● Pass/Fail function
●Thirty two parameters Auto measure function
● Cursor measure covers Manual mode, Track mode and Auto mode
● Channel waveform and it's FFT waveform display on split screen
● Pop-up Menu display pattern is more convenient for users using it
● Multiple Language User Interface
● Support Multilingual online help system
Siglent oscilloscopes include:
2 x Probe's
1 x Power cord
1 x USB cable
1 x Manual
1 x CD with software
Specifications
|
Model |
Siglent SDS1302CFL |
|
Bandwidth |
300MHz |
|
Channels |
2CH+1EXT |
|
Real time sampling rate |
1GSa/s (each channel), 2GSa/s (half channel) |
|
Equivalent sampling rate |
50GSa/s |
|
Memory depth |
12K (each channel), 24k (half channel) |
|
Rise time |
< 1.2ns |
|
Input impedance |
1MΏ‖13pF, 50Ω |
|
Time base range |
1.0ns/div-50s/div |
|
Scan: 100ms-50s/div |
|
|
Vertical sensitivity |
2mV - 5V/div |
|
Vertical resolution |
8 bit |
|
Trigger source |
CH1, CH2, CH3, CH4, Ext, Ext/5, AC Line |
|
Trigger types |
Edge, Pulse, Video, Slope, Alternative |
|
Math Operation |
+, -, x, ÷, FFT |
|
Digital filter |
High pass, Low pass, Band pass, Band Stop |
|
Max input voltage |
±400V (DC+AC Pk-Pk), CAT I, CAT II |
|
Internal storage |
2/4 groups reference waveform, 20 groups of settings, 20 groups of waveforms |
|
External storage |
Bitmap save, CSV save, Waveform save, Setting save |
|
Language |
English, French, German, Russian, Spanish, Simplified Chinese, Traditional Chinese, Portuguese, Japanese, Korean, Italian, Arabic |
|
Interface |
Double USB Host, USB Device, LAN, Pass/Fail out |
|
Display |
7" colour TFT-LCD |
|
Power |
AC 100-240V, 45Hz-440Hz, 50VA Max |
|
PC software |
Can through the computer remote control oscilloscope, extraction waveform analysis data |
|
Remark |
With original source seamless connection, form signal collection, produce integration system |
