Siglent SSG3021X-IQE 9 kHz ~ 2.1 GHz Signal Generator
Description
Product Description
SIGLENT’S SSG3021X-IQE signal generators hase a frequency range of 9 kHz to 2.1 GHz. The SSG3021X-IQE provides normal analog modulation such as AM, FM, and PM. It also provide pulse modulation and pulse train generator
In addition, when used with baseband generator such as SDG6000X, They can generate IQ modulated signals. With their high accuracy and pure outputs, the SSG3000X series is the right choice for R&D, education, and manufacturing.
Key Features:
- Includes built-in high precision, 200 MHz frequency counter
- Multiple modulation functions, sweep-frequency function, pulse train function
- Standard PC connections: USB Device, USB Host, U-Disk storage and software, GPIB (optional)
- Seamlessly connects to the SDS series digital oscilloscopes
- Remote computer control
5 inch touch screen, keyboard and mouse support
/f.jwwb.nl%2Fpublic%2Fy%2Fs%2Fv%2Ftemp-vehueauhmxnzwujrdbsr%2Fo0ec4c%2FSSG3000X-5-2.jpg)
External IQ modulation using the SDG6000X as the baseband source
/f.jwwb.nl%2Fpublic%2Fy%2Fs%2Fv%2Ftemp-vehueauhmxnzwujrdbsr%2Fevh0z0%2FSSG3000X-6-3.jpg)
Maximum output level up to +20 dBm
Provides double-tone signal with IQ modulation,
easily do TOI testing
Specifications Download :Spec Sheet Download
Accessoires Included:
1 x Siglent SSG3021X-IQE Signal Generator
1 x Quick start Guide
1 x Guarantee Card
1 x Power Cord
1 x USB Cable
