OX 6202B SD oscilloscope

Description

Description

The OX 6202B oscilloscope is also a "real-time" FFT analyser. With its 2 x 300 V Cat. II measurement channels, it can display up to 4 curves on screen.
Equipped with a removable SD card, the OX 6202B's recording and storage capacity has now been increased to 2 GB!


These ergonomic, compact instrument include a storage space for stowing the cables and probes.
On the front panel, 28 command keys are directly accessible and "Windows-like" menus make the OX 6202B even simpler to use.

Other specifications:

Additional specifications:
Display: LCD with backlighting, 4 curves + 4 references.
Bandwidth: 200 MHz
Vertical resolution: 10-bit converter and 4-digit display
Wide dynamic input range: 2.5 mV to 100 V/div
Memory depth: 2,500 points/channel and up to 50,000 points/channel with the Extended Acquisition Memory option
Advanced triggering: Auto, Normal, One-shot, Auto level 50 %, CH1, CH2, EXT, LINE, Edge, Pulse Width, TV Frame, TV Line, Hold-off
Multimeter: 2 x 4,000-count channels + min/max bargraph, time/date-stamped graphic recording
Other measurements: resistance, continuity, capacitances, frequency, temperature, diode test.
Communication: local Ethernet, RS232 & USB
Network: 10 MB remote Ethernet, Web server (remote control, "real-time" trace, cursors and automatic measurements, FTP server (for exchanging files with a PC), FTP client (storage on PC hard disk), administration utility
"SX-Metro" application software for PC
